Description
An latest optical fingerprint scanner, it is developed by ZKTeco. It supports finger detection and captures fingerprint image fast, with high resolution. The product is small, easy to use fingerprint registration on the desktop. Low power consumption, it also applies to Android tablet and mobile phone. We provide SDKs for customers to develop their own applications.
Features
- Operating System: Windows, Android, Linux
- Frequency: 13.56MHz
- Read Range: Up to 3 cm
- Communication: USB
- Operating Temperature: -10 degree Celsius to 70 degree Celsius
- Material: Industrial ABS Plastic
- Dimension: 117.2*66.2*17 (mm)
- USB charging
- Plug & play
- LED indicator and buzzer feedback
ZKTeco LIVE 10R Specifications
| Product Model |
LIVE 10R |
| Sensor Type |
Optical |
| Effective Sensing Window |
16.5 × 23 mm |
| Effective Sensing Area |
15.24 × 20.32 mm |
| Image Size |
300 × 400 pixels |
| Image Resolution |
500 DPI |
| Operating System |
Windows, Android, Linux |
| Domestic Operating Systems |
Supported (Galaxy Kirin, Zhongbiao Kirin, Tongxin OS — including Phytium, Loongson, Feiteng, Haiguang, Zhaoxin platforms) |
| Power Supply |
5V USB power |
| Working Temperature |
-20 ~ 55 °C |
| Working Humidity |
0% ~ 90% (non-condensing) |
| Communication Method |
USB 2.0, compatible with USB 1.1 |
| Supported Algorithm |
ZKFINGER V10.0 |
| Product Dimensions (L × W × H) |
75.5 × 53.2 × 19 mm |
| Net Weight |
<90 g |
